RCF ART-915A-AX Active 2100W 15″ Speaker W/ Mixer & Bluetooth

DESCRIPTION

ART 915-AX is a top-notch solution for any audio application, featuring 48V microphone preamps and line inputs, an internal 6-channel digital mixer with advanced DSP, Bluetooth stereo audio input, with dual speaker pairing option. The combination of a 1.75″ compression driver, 15″ woofer, and two-channel 2100W amplifier, produces 100 x 60 constant directivity coverage for the listening area with up to 131 dB SPL, distortion-free sound. The sleek cabinet uses a special polypropylene composite material with an M-brace internal reinforcement, making it easy to carry and secure to install on a pole, flown-, wall-, or truss-mounted using the multiple rigging points available.

• Built-in 6-channel Digital Mixer
• Advanced User Interface w/ touch panel and remote control
• 1.75″ Compression Driver and 10″ Woofer
• Up to 130 dB Sound Pressure Level
• 2100W Class-D Bi-Amplification
• Dual combo preamp with 48V Power and Mini-jack stereo line input
• Bluetooth stereo audio input, with dual speaker pairing option
• True Resistive Waveguide, FiRPHASE, and Bass Motion Control

SPECIFICATION

Acoustical Specifications

• Frequency Response: 45 Hz 20000 Hz
• Max SPL @ 1m: 131 dB
• Horizontal coverage angle:100
• Vertical coverage angle:60

Transducers

• Compression Driver: 1 x 1.0”, 1.75” v.c
  Woofer: 15”, 2.5” v.c

Input/Output section

• Input signal:bal/unbal
• Input connectors: Combo XLR/Jack
• Output connectors: XLR

Processor section

• Crossover Frequencies: 1600Hz
• Protections: Thermal, RMS
• Limiter: Soft Limiter
• Controls: Color touch panel, data entry/volume encoder, dedicated App for iOS and Android.

Power section

• Total Power:2100 W Peak
• High frequencies: 700 W Peak
• Low frequencies: 1400 W Peak
• Cooling: Convection
• Connections:VDE

Electronic Specifications

• Frequency Response:20 Hz 20 Hz
• THD+N, 20dB gain, 0dBu out: 0.005% A-Weighted

Processing

• Processing Channels:6
• Signal Processing: 24 Bit
• A/D-D/A conversion: 32 Bit @ 48.0 kHz
• Dynamic range: 110

Inputs

• Mic:2
• Remote Controlled Storable Gain: Yes
• Gain Range: 0 dB 42 dB
• Input Noise Level: -114 dBu A-Weighted
• Mic Inputs Impedance: 6 kohm
• Low Cut: 20 Hz 400 Hz
• Phantom Power +48V: Yes
• Mono Line: 2
• Gain Selection: 0 dB 22 dB
• Line Input Impedance: 21 kohm
• A/D Dynamic range: 114 dB
• Stereo Line: 1
• Gain Selection: 0 dB 10 dB
• Stereo Line Input Impedance (kOhm): 13 kohm

Outputs

• Main MIX:1

Outputs Specifications

• Main Out Impedance:150 ohm
• Main Out Level: 22 dBu
• D/A Dynamic Range:114 dB

Compressors

• RCF Compressors:Compressors on MIC/LINE CH1 & CH2 Inputs

EQ

• Input Channels EQ:2 Shelving 1
• Description: 3 Band EQ: High and Low band shelving, MID band peak on IN
  5 Band EQ: 4 Full Parametric, 1 High Shelving and HPF 24 dB/Oct on amplifier and MAIN output.

Internal Effects

• Send Effects:1

Mastering Processors

• Main OUT type:MIX OUT, CROSSOVER OUT with RCF SUBWOOFERS presets, STEREO OUTPUT, CH1 LINK OUT.

Standard Compliance

• Safety agency:CE compliant

Physical Specifications

• Cabinet/Case Material:PP Composite
• Hardware: 1 x M10 top, 1 x M10 each side
• Handles: 1 top, 1 each side
• Pole mount/Cap: 35 mm insert
• Grille: Steel
• Color: Black

Size/Weight

• Height: 717 mm / 28.23 inches
• Width: 415 mm / 16.34 inches
• Depth: 410 mm / 16.14 inches
• Weight: 20.4 kg / 44.97 lbs
